CANYON Ablation System

A New Portable Generation - Spherical Series & Standard Antennas

CANYON Microwave Ablation System is a new portable solid state system that ensures stable microwave output. It comes with an interactive and sensitive touchscreen with adjustable power, time, and temperature which makes it very user-friendly. In addition, its innovative interface allows the user to monitor and provides instant feedback for safe use.

Continuous and pulsed modes are available for different clinical options.

  • High performance material to ensure better connection and strength
  • Unique shaft coating material to avoid tissue adhesion
  • Sharp needle tip and thin diameter, making it less invasive
  • Internally water cooled antenna with intelligent temperature control
  • Signal enhancement design for better visibility under CT or ultrasound guidance
  • High efficiency detachable cable, unique enhanced connection with the antenna
  • Patented radiation control technology and fully cooled antenna that guarantees an ultraspherical shape of the ablation zone
  • Enhanced product safety that gives the benefit of strength and stiffness
  • New coating which gives the user a perfect and smooth puncture movement, also avoiding tissue adhesion in an efficient way
  • Echogenic design that gives the user enhanced visibility
  • Available in 14G and 15G in different lengths
Ref. no Frequency Display Energy Output Time Setting Working Power Weight Size
H-1 2450 Mhz 7 inch Touchscreen 5-100W 1-30 Minutes 100V-240V 50-60 Hz 9.8 kg 42x39x22cm
Ref. no Description Frequency Diameter Active Tip Total Length
KY-2ABP-11A MWA Standard Antenna 2450 MHZ 16G 3 MM 100 MM
KY-2BBC-24D MWA Standard Antenna 2450 MHZ 16G 11 MM 200 MM
KY-2BAC-24A MWA Standard Antenna 2450 MHZ 15G 11 MM 100 MM
KY-2BAC-24B MWA Standard Antenna 2450 MHZ 15G 11 MM 150 MM
KY-2BAP-24C MWA Standard Antenna 2450 MHZ 15G 11 MM 180 MM
KY-2BAC-24D MWA Standard Antenna 2450 MHZ 15G 11 MM 200 MM
KY-2BAC-24F MWA Standard Antenna 2450 MHZ 15G 11 MM 250 MM
KY-2450B-5 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 16G 3 MM 100 MM
KY-2450B-T3 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 16G 11 MM 200 MM
KY-2450B-T4 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 15G 11 MM 100 MM
KY-2450B-T6 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 15G 11 MM 150 MM
KY-2450B-T7 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 15G 11 MM 180 MM
KY-2450B-T8 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 15G 11 MM 200 MM
KY-2450B-T10 Set - MWA Standard Antenna and Co-axial Cable 2450 MHZ 15G 11 MM 250 MM
KY-2450B-QT4 MWA Antenna - Spherical Series   15G 25 MM 100 MM
KY-2450B-QT5 MWA Antenna - Spherical Series   15G 25 MM 150 MM
KY-2450B-QT6 MWA Antenna - Spherical Series   15G 25 MM 200 MM
KY-2450B-QT7 MWA Antenna - Spherical Series   15G 25 MM 250 MM
KY-2450B-QT MWA Antenna - Spherical Series   14G 25 MM 200 MM
KY-2450B-QT1 MWA Antenna - Spherical Series   14G 25 MM 100 MM
KY-2450B-QT2 MWA Antenna - Spherical Series   14G 25 MM 150 MM
KY-2450B-QT3 MWA Antenna - Spherical Series   14G 25 MM 250 MM



Ref. no Description Length
KY-B-2B-B-200 Co-axial Cable - Spherical Series. Blue x20 reusable 2000 MM
KY-B-2B-G-280 Co-axial Cable - Standard Antennas. Grey x20 reusable 2800 MM
KY-NP-1-01 Trolley for use with H-1 generator
